Tennant CS16 Service Field Guide: Advanced Diagnostics & Component Testing

1. QUICK SPECIFICATIONS & BENCHMARKS MATRIX

Electrical System Benchmarks

Operating System Voltage (Battery Model): $24\text{V DC} \pm 1\text{V}$
Solenoid Valve Terminal Voltage: 21.4V - 25V DC (when handle lever is pulled)
Power Board MOS-FET Thermal Cutoff Limit: $150^\circ\text{C}$
Board Mounting Screw Torque: $3\text{ Nm}\ (26.55\text{ lbf-in})$ (Must apply thermal conductive paste to back plate)
Brush Motor Mounting Bolt Torque: $9\text{ Nm}\ (79.66\text{ lbf-in})$
Brush Head Pivot Bolt Torque: $23\text{ Nm}$

Motor Current Draw & Wear Limits Table

Component	Test Condition	Min Current	Max Current	Wear Threshold / Replacement Limit
24V DC Brush Motor	No Load (Brush Raised)	$2.0\text{ A}$	$3.5\text{ A}$	Carbon brush length $< 8.0\text{ mm}\ (0.31\text{ in})$
24V DC Brush Motor	Light Load (Empty Tank)	$7.0\text{ A}$	$9.0\text{ A}$	Replace all 4 carbon brushes simultaneously
24V DC Brush Motor	Full Load (Full Tank, Standard Brush)	$9.0\text{ A}$	$11.0\text{ A}$	Cutoff threshold: > 15 A for 20 sec
24V DC Suction Motor	No Load (Tank Removed)	$13.0\text{ A}$	$17.0\text{ A}$	Carbon brush length $< 6.0 - 8.0\text{ mm}$
24V DC Suction Motor	Overload Limit	—	$> 30\text{ A}$	Cutoff threshold: > 30 A for 20 sec

2. DISPLAY DASHBOARD ALARM CODES & METER FLOWCHART

NOTE: Internal motor thermal trip, blown individual motor fuses, or severed motor power cables do not display dashboard error codes.

                     DASHBOARD LED ERROR IDENTIFICATION
                                     │
    ┌───────────────────┬────────────┴───────┬───────────────────┐
    ▼                   ▼                    ▼                   ▼
2 FLASHES           2 FLASHES            4 FLASHES          FAST FLASHING
(Brush LED)         (Suction LED)        (Brush LED)        (Both LEDs)
    │                   │                    │                   │
Short Circuit /     Short Circuit /      Brush Motor         Power Board MOS-FET
Peak Current        Peak Current         Internal Thermal    Overheating
    │                   │                Protector Tripped   (>150°C)
    │                   │                    │                   │
    ├─► Check motor     ├─► Check motor      ├─► Check for       ├─► Allow 15 min
    │   wiring short.       wiring short.        motor binding.      cool-down.
    │                   │                    │                   │
    └─► Verify rotor    └─► Check fan        └─► Test continuity └─► Check current
         spins free.         rotates free.       on 4-pin purple-    draw on both
                                                 black wires.        motors.

Detailed Error Troubleshooting Steps

2 Quick Flashes — Brush Motor Short Circuit Protection

Disconnect battery power.
Rotate brush manually to ensure motor is not mechanically locked/jammed.
Disconnect power harness from brush motor terminals. Check for continuity/short to frame.
Test motor directly with isolated 24V source. If motor draws excessive peak current, inspect rotor/commutator or replace motor assembly.

2 Slow Flashes — Motor Overload

Brush Motor Limit: Exceeding 15 A for > 20 seconds
Suction Motor Limit: Exceeding 30 A for > 20 seconds
Fix Action: Check brush pad aggressiveness/friction on floor surface , inspect carbon brushes , and check for string/debris bound in the drive reduction gearbox.

4 Flashes — Brush Motor Thermal Protector Tripped

Motor thermal cutout is a Normally Closed (NC) switch operating between $80^\circ\text{C} - 110^\circ\text{C}$ .
Bench Check: Detach the 4-pin connector on the main harness and check continuity across the two purple-black wires.
If open-circuit while motor is cool, replace the internal thermal protector.

3. COMPONENT DIAGNOSTIC DECISION TREES

Tree A: Machine Completely Inoperative (No Display LEDs)

Check Battery Voltage: Ensure voltage across main terminals is > 21.5V DC
Check Fuse F1: Inspect 30A Main Fuse on battery model (8A Fuse F1 on corded model).
Verify Charger Lockout Relay: Disconnect battery charger bullet connectors E1 and bridge harness connectors E2 to bypass charger interlock relay. If control panel powers on, replace charger module.
Check Ribbon Cable: Test 10-pole flat ribbon cable for continuity pin-to-pin between function board and power board.

Tree B: Solution / Water Flow Failure

                          NO WATER AT BRUSH HEAD
                                     │
      ┌──────────────────────────────┴──────────────────────────────┐
      ▼                                                             ▼
[ SOLENOID CLICK AUDIBLE ]                             [ NO SOLENOID CLICK ]
      │                                                             │
      ├─► Clean inline solution filter (if equipped).               ├─► Verify 21.4V-25V DC across valve
      │                                                                 fast-on terminals when lever pulled.
      ├─► Flush solution dispensing cock under tank.                │
      │                                                             ├─► IF VOLTAGE PRESENT: Solenoid coil
      └─► Disassemble solenoid valve & clear diaphragm                  faulty or valve membrane seized.
          outlet hole E.                                                Replace solenoid coil/assembly.
                                                                    │
                                                                    └─► IF NO VOLTAGE: Test output from
                                                                        power board contact J3 / check 10-pole
                                                                        ribbon cable continuity.

4. POWER BOARD & CHARGER SERVICE PROTOCOL

Replacing the Power Control Card

Thermal Dissipation Safety: Clean mounting plate thoroughly. You must apply a fresh layer of thermally conductive silicone paste to the back of the new power card prior to mounting.
Torque Spec: Tighten all 4 board mounting bolts E to 3 NM. Do not over-torque.

Battery Charger DIP Switch Configuration (SW2)

When swapping battery chemistry, configure switch SW2 on the internal charger board:

      EXIDE GEL (Default)           DISCOVER AGM                 LEAD-ACID (WET)
        [ SW2 Board ]               [ SW2 Board ]                [ SW2 Board ]
        ┌───────────┐               ┌───────────┐                ┌───────────┐
     1  │  ■  OFF   │            1  │  ■   ON   │             1  │  ■  OFF   │
     2  │  ■  OFF   │            2  │  ■   ON   │             2  │  ■  OFF   │
        └───────────┘               └───────────┘                └───────────┘

Confirmation Verification: Upon plugging AC power into wall, observe status LED:
- 2 Green Flashes: Configured for Gel / AGM profile.
- 2 Red Flashes: Configured for Wet / Lead-Acid profile.
