The maneuverability of a mop with the cleaning performance of a walk-behind floor scrubber. The i-mop^® XL Plus makes it possible to clean any floor surface with freedom of movement and great ease of use. No borders or boundaries. This machine isn't just designed for cleaning, it is designed for the cleaner.

Parameter	Metric Measurement	Imperial Measurement
Cleaning Path	460 mm	18.1 in
Solution Tank	4 L	1 gal
Main Down Pressure	22.5 kg	Up to 48.4 lbs

I-MOP XL PLUS FEATURES

HIGHLIGHTS

Remove more surface soil than traditional mop and bucket cleaning with the i-mop XL Plus’ balanced weight distribution and twin counter-rotating brushes.
Increase productivity, minimize foot traffic disruptions, create a more inviting facility and reduce the risk of slip and fall injuries with improved cleaning performance versus manual mopping.
Relieve the operator of extra weight with the i-balance mechanism and prevent the machine from falling.
Protect the vacuum motor from overflowing water with a floating ball in the filtration element that pops up and engages to close the recovery tank when it is full.
Keep your motor safe from water damage with an electronic switch that automatically shuts down the motor when held below a 32 degree angle.
Prevent your battery from draining with the i-mop's battery safe guard that ensures the machine remains off when in storage mode.
Easily clean or replace squeegee with the quick change squeegee assembly.

I-MOP XL PLUS SPECIFICATIONS

Application: Indoor
Estimated Coverage/Productivity: Up to 19375 sq ft / 1800 sq m
Estimated Run Time: Up to 70 mins
Main Down Pressure: Up to 48.4 lbs / 22.5 kg
Power Source: Lithium-Ion Battery
Sound Level: As low as 79.6 dBA
Service Plans: Pay as You Go
Machine Height: 47.2 in / 1199 mm
Machine Length: 13.8 in / 350.5 mm
Weight: 58.9 lbs / 26.7 kg (with batteries and water)

Charger type: Off-board
Cleaning Path: 18.1 in / 460 mm
Machine Type: Walk-Behind
Recovery Tank Capacity: 1.5 gal / 6 L
Pad RPMs: Up to 350 rpm
Solution Tank Capacity: 1 gal / 4 L
Battery Charger Type: Battery
Head Type: Disk
Machine Width: 18.9 in / 480 mm

I-MOP XL PLUS KEY BENEFITS

Easy Operation & Maintenance

Easily clean floors with the flexibility of a mop and the power and speed of a scrubber.

Improve cleaning performance with twin 350 RPM counter-rotating brushes.
Easily clean around and underneath objects with a unique ergonomic design that allows for one-handed operation.
Get ultimate cleaning flexibility and eliminate the risk of tripping accidents caused by cords.
Make swift work out of any cleaning job with a cleaning path up to 18 in / 46 cm wide and up to 48.4 lbs / 22.5 kg of down pressure.
Customize your cleaning experience with a variety of brush and pad options to meet your facility's needs.
Fill, empty and re-fill tanks virtually anywhere – not just slop sinks.
Easily transport between different areas, levels and buildings with i-mop's convenient wheels.
