The new Tornado Surge 500 and 220 Carpet Extractors provide a winning combination of 15 gallon solution and recovery tanks and a 133 CFM vacuum for greater cleaning capacity and reduced drying times. These units include a powerful wand and feature an Airwatt motor specifically designed for wet pick-up and unmatched protection against moisture, with sealed-bearings and an electronic float shutoff. Designed with the user in mind, Surge extractors include on-board storage for the hose, wand, cords and chemicals, easy to access controls, and time-saving features to fill, drain and maintain your machine.

Built-in storage for the included wand, hose, and power cords and for chemicals makes it easy to transport and store this unit.

Easy to fill and empty, with a 10-foot sink fill hose, wide opening designed for bucket pours, and front-mounted drain hose

Intuitive controls all conveniently located on top of the machine, reducing the need to reach or bend over while operating the machine.

Increased mobility with large 12” rear wheels, a unique stair-assist design and handle-mounted transport wheels.

The rear service panel and clamshell design allow easy access to the pump, vac and heater, drastically reducing downtime for repairs and maintenance.

Features an Airwatt Motor, the industry’s only vacuum motor specifically designed for wet pick-up, with sealed bearing to prevent premature failure from moisture.

Surge 500 Spec Sheet Download PDF

Surge 220 Spec Sheet Download PDF

Surge 500 Operations Manual Download PDF

Surge 220 Operations Manual Download PDF

Name	Surge 220	Surge 500
Model #	TE200-G15-U	TE310-G15-U
Solution & Recovery Tank Capacity (ea.)	15 Gallons	15 Gallons
Vac Motor	Single Airwatt (625 Watts)	Single Airwatt (625 Watts)
CFM	133	133
Waterlift	125"	125"
Solution Pump (PSI)	220	50-500
Heater	Single Element	Single Element
Max Heat	190	190
Vacuum/Solution Hose	20 Ft. Insider Hose	20 Ft. Insider Hose
Vacuum Hose Diameter	1.5"	1.5"
Cord Configuration	Dual Circuit	Dual Circuit
Amp Draw	15 amps	15 amps
Front Wheels	4" Casters	4" Casters
Rear Wheels	12"	12"
Wand (included)	Up to 800 PSI	Up to 800 PSI
Weight (lbs)	152	152
Dimensions (LxWxH)	36.5"x23.5"x45.5"	36.5"x23.5"x45.5"
