The newly redesigned SC901 is ideal for heavy cleaning environments that require the use of a reliable and durable machine to do the job, every time.

Available in 28- and 34-inch disc and 32-inch cylindrical models, the large capacity tanks are ideal for cleaning education and healthcare facilities, municipal and government buildings, as well as grocery stores.

Designed to do the Job. Every Time.

Available in 28 and 34 inch disc or 32 inch cylindrical scrub paths
30 gallon solution tank
32 gallon recovery tank
Simple and easy to use paddle interface
Minimal electronics for increased reliability and lower total cost of ownership
Control board-free design eliminates costly repairs
Mechanical scrub and vacuum levers
Regulated cruise control increases productivity and safety
Simplified user interface

Models	SC901™ 28D	SC901™ 34D	SC901™ 32C
Head Type	Disc	Disc	Cylindrical
Cleaning Width	28 in (71 cm)	34 in (86 cm)	32 in (81 cm)
Maximum Scrub and Transport Speed	3.2 mph (5.15 km/hr)	3.2 mph (5.15 km/hr)	3.2 mph (5.15 km/hr)
Productivity Per Hour Maximum (ISSA 540)	28,028 ft2/hr (2,604 m2/hr)	34,034 ft2/hr (3,162 m2/hr)	31,915 ft2/hr (2,965 m2/hr)
Drive Motor	0.5 hp	0.5 hp	0.5 hp
Solution Tank	30 gal (114 L)	30 gal (114 L)	30 gal (114 L)
Recovery Tank	32 gal (121 L)	32 gal (121 L)	32 gal (121 L)
Flow Rate	0-1 GPM (3.8 LPM)	0-1 GPM (3.8 LPM)	0-1 GPM (3.8 LPM)
Brush Motor	0.75 hp	0.75 hp	0.75 hp
Brush Speed	250 RPM	250 RPM	900 RPM
Brush Down Pressure	80, 145, 200 lb (36, 66, 91 kg)	80, 145, 200 lb (36, 66, 91 kg)	75, 100, 125 lb (34, 45, 57 kg)
Vacuum Motor	0.95 hp	0.95 hp	0.95 hp
Maximum Vacuum Motor Waterlift	71 in H2O (17.7 KPA)	71 in H2O (17.7 KPA)	71 in H2O (17.7 KPA)
Maximum Vacuum Motor Air Flow	96 CFM (2,718 LPM)	96 CFM (2,718 LPM)	96 CFM (2,718 LPM)
Sound Level (IEC, ISO 11201)	68 dB A	68 dB A	69 dB A
Width Without Squeegee	30.3 in (77 cm)	30.3 in (77 cm)	30.6 in (77.7 cm)
Width With Squeegee	41.8 in (106.6 cm)	41.8 in (106.6 cm)	41.8 in (106.6 cm)
Height	44.8 in (113.8 cm)	44.8 in (113.8 cm)	44.8 in (113.8 cm)
Length	65.4 in (166 cm)	67.4 in (171 cm)	63.1 in (160.3 cm)
Floor Loading Right Front	147 PSI (1.0 N/mm2)	128 PSI (0.88 N/mm2)	155 PSI (1.1 N/mm2)
Floor Loading Left Front	107 PSI (0.74 N/mm2)	132 PSI (0.91 N/mm2)	128 PSI (0.88 N/mm2)
Floor Loading Right Rear	205 PSI (1.4 N/mm2)	432 PSI (3.0 N/mm2)	245 PSI (1.7 N/mm2)
Floor Loading Left Rear	521 PSI (3.6 N/mm2)	640 PSI (4.4 N/mm2)	416 PSI (2.9 N/mm2)
Gross Weight (310 Ah batteries, Full Solution Tank)	1,189 lb (539.3 kg)	1,206 lb (547 kg)	1,235 lb (560 kg)
Protection Grade	IPX4	IPX4	IPX4
Gradeability Transport and Cleaning	2%, 1.15 degrees	2%, 1.15 degrees	2%, 1.15 degrees
Battery Options (36 V, 6 ea, 6 V)	242 Ah wet, 310 Ah wet,	242 Ah wet, 310 Ah wet,	242 Ah wet, 310 Ah wet,
	255 Ah AGM	255 Ah AGM	255 Ah AGM
